Product Overview

Test signals for TV and audio broadcasting – handy and economical.

The R&S SFC compact modulator is an economical multistandard signal source. It supports realtime coding for all conventional digital and analogue TV and audio broadcasting standards. The R&S SFC is equipped with a built-in computer, making it ideal for standalone operation and for integration into a signal generation system with multiple generators.

Category:

Related products

Key Features

  • High precision modulator with MER > 40 dB
  • VHF and UHF frequency range, optionally up to 3 GHz
  • Level range from 0 dBm to –31.5 dBm, optionally to –110 dBm
  • Terrestrial TV standards: DVB-T2, DVB-T, DVB-H, DTMB, CMMB, T-DMB, ISDB-T, ISDB-TB, ATSC/8VSB, ATSC-M/H
  • Cable TV standards: DVB-C2, DVB-C, J.83/B, ISDB-C
  • Satellite TV standards: DVB-S2, DVB-S, DIRECTV
  • Analogue TV standards: B/G, D/K, I, M/N, L
  • Audio broadcasting standards: DAB, DAB+, ISDB-TSB, AM/FM/RDS
  • Integrated transport stream player and analogue audio/video generator
  • Transport stream libraries and test pattern libraries supported
  • Integrated AWGN generator
  • ASI transport stream input
  • Digital I/Q input to connect to other Rohde & Schwarz broadcasting signal generators
